GLM-5.2 vLLM Block-Table Errors: Fixed Versions

Independent research — not an official Z.ai publication.Identity and provider disclosure

AI Infrastructure Editor

Editorial responsibility: GLM52.ai Editorial TeamPublished and editorially reviewed August 27, 2026

How we research and review Report a correction

Disclosed editorial pen name · AI-generated portrait

A cool-blue diagnostic flow compares a narrow block table with a one-column amber extension labeled alignment and a second pair whose wider table is exactly twice the narrow table labeled DCP2, then routes them to vLLM 0.27 and 0.28 release checkpoints

Original editorial diagnostic. It visualizes width relationships; it is not a vLLM screenshot, CUDA trace, benchmark result, or proof of a fixed cluster.

The traceback looks like a generic PyTorch shape failure:

RuntimeError: The expanded size of the tensor (...) must match
the existing size (...) at non-singleton dimension 1

For GLM-5.2’s DSA sparse-indexer path, the two numbers are more useful than the word “expanded.” They reveal which code paths calculated different block-table widths. Treating every pair as an off-by-one can hide a DCP configuration bug; treating every pair as DCP can hide a stale table created before an automatic context reduction.

This guide audits the public GLM-5.2-FP8 checkpoint at ba978f7d…, vLLM issue #46074, merged alignment fix #50302, DCP issue #50825, and merged DCP fix #50823. The machine-readable receipt hashes 22 public artifacts and regenerates the width tables. We made zero model calls, zero local GPU runs, and zero local upstream-test runs.

In this guide

Classify the three width signatures
Reproduce the one-column alignment math
Verify the alignment fix in v0.27.0
Reproduce the DCP-factor mismatch
Verify why DCP waits for v0.28.0
Choose a stable version from the matrix
Inspect the installed source without a GPU
Use the ratio as a diagnostic, not a verdict
Run a one-variable upgrade canary
Test MTP and prefix caching separately
Handle an old-version workaround carefully
Separate nearby GLM-5.2 failures
Rent a test cluster only after preflight
Frequently asked questions
Sources and method

Classify the three width signatures

Start with the two dimension-1 widths, the resolved KV cache type, selected attention backend, DCP size, and whether vLLM changed max_model_len during startup. Do not begin by adding an arbitrary column to a tensor.

Logged relationship	Likely calculation disagreement	Upstream boundary	First stable release
Difference is exactly 1: `1563/1564`, `3125/3126`, `5469/5470`	One side applies 128-token alignment to 64-token blocks; the indexer side does not	PR #50302	v0.27.0
Larger width is exactly `dcp_size ×` smaller width: `8192/16384` under DCP2	Uniform group spec is unsharded while its MLA layer spec is DCP-sharded	PR #50823	v0.28.0
Widths map to old and reduced context limits: `2464/3168`	`InputBatch` retains the original width after `max_model_len=auto` changes	Open PR #46794 at this audit	No stable boundary established here
No relationship matches	Different runner, block size, kernel split, MTP overhang, or another defect	Source-audit the actual build	Do not guess

The table is a routing aid, not a stack-free classifier. Confirm the failure site includes the MLA/DSA indexer and a copy into expanded_block_table_buffer. A failure in weight loading, KV allocation, FlashMLA workspace allocation, MoE kernels, graph capture, or NCCL belongs to a different investigation.

The upstream reports use fp8_ds_mla, FLASHMLA_SPARSE, concurrent decode, and MTP in several profiles. Those details make the bug reachable; they do not mean every FP8, MTP, or long-context failure has the same root cause.

Reproduce the one-column alignment math

The alignment case is deterministic. GLM-5.2’s reported sparse path uses 64-token KV blocks. Some attention backends require the block table to cover a 128-token quantum. vLLM therefore needs an even number of 64-token columns:

block_alignment = 128 / gcd(128, 64) = 2

raw_blocks     = ceil(max_model_len / 64)
aligned_blocks = ceil(raw_blocks / 2) × 2

If raw_blocks is odd, alignment adds one column. If it is even, both widths already match.

`max_model_len`	Raw width	Aligned width	Delta	Upstream result
100,000	1,563	1,564	+1	Earlier GLM sparse-indexer report
106,816	1,669	1,670	+1	PR regression case
200,000	3,125	3,126	+1	H200 reproduction comment
230,000	3,594	3,594	0	Stable in issue #46074
300,000	4,688	4,688	0	Stable in issue #46074
325,000	5,079	5,080	+1	Crash in issue #46074
350,000	5,469	5,470	+1	Primary issue crash

The calculation reproduces both the exact 5469 vs 5470 exception and the reported stable/crash parity at 230K, 300K, 325K, and 350K. That is strong source-level evidence for the width diagnosis. It does not reproduce the reporter’s 4-node, 32-H100 service or its request success rate.

Issue #46074 also records a separate H200 observation at 200,000 tokens with MTP and heavy prefix-cache hits. The logged pair was 3125 vs 3126. The same parity explains the width, but the trigger shows why “it only fails above 325K” is too broad. Workload state can bring the edge into an otherwise lower configured limit.

Verify the alignment fix in v0.27.0

Before the fix, MultiGroupBlockTable rounded its width while the sparse indexer allocated expanded_block_table_buffer from an unaligned cdiv. Both objects described the same request but reserved different column counts.

Merged PR #50302 moved the calculation into one get_block_table_width helper. The model runner, block table, metadata builder, and indexer then consume the same aligned width. Its CPU regression includes get_block_table_width(1875, 64) == 1876 and also checks virtual kernel-block splitting.

The source boundary is verifiable rather than inferred from release dates. A release date alone is not commit containment:

v0.26.0 block_table.py contains the old local alignment and no shared helper.
v0.27.0 block_table.py defines get_block_table_width.
v0.27.0 indexer.py requires the calculated block_table_width rather than recomputing it.
The v0.27.0 tag descends from merge commit a0cd2b69….

Therefore v0.27.0 is the first stable release containing the alignment fix. This statement is limited to that defect. It does not make v0.27.0 the answer for the DCP-factor signature.

Reproduce the DCP-factor mismatch

The DCP failure predates the alignment fix but appears through the same tensor copy. One side reads a uniform cache-group spec; the other reads its per-layer MLA spec. Before PR #50823, their width formulas differed:

group_width     = ceil(max_model_len / block_size)
per_layer_width = ceil(max_model_len / (block_size × dcp_size))

For issue #50825’s GLM-5.2 DCP2 profile:

max_model_len = 1,048,576
block_size    = 64
dcp_size      = 2

group_width     = 1,048,576 / 64       = 16,384
per_layer_width = 1,048,576 / (64 × 2) = 8,192

The larger width is exactly twice the smaller width because DCP size is two. This is not 128-token parity: both numbers are already even. Adding a single column cannot reconcile them.

PR #50823 makes UniformTypeKVCacheSpecs.max_num_blocks_per_req delegate to its constituent layer specs and asserts they agree. Its CPU test reduces the same relationship to 1,024 tokens, 16-token blocks, and DCP2: the old group reports 64 while the layer reports 32; after the fix both report 32.

Verify why DCP waits for v0.28.0

PR #50823 merged on August 3, before v0.27.0 was publicly released on August 10. That chronology is tempting but insufficient. A release branch can be cut before a main-branch merge.

The tagged files settle the question:

Tag	`UniformTypeKVCacheSpecs` DCP-aware width override	File receipt
v0.27.0	Absent	`bfbd62f0…`
v0.27.1	Absent	`bfbd62f0…`—byte-identical for the audited file
v0.28.0	Present	`932e9175…`

The v0.28.0 tag also descends from merge commit f0de1a60…. It was released on August 26. Thus v0.28.0 is the first stable release containing the DCP group-width fix and the first audited stable tag containing both fixes in this guide.

Do not read this as “v0.27.1 is generally broken for DCP” or “v0.28.0 makes every GLM-5.2 DCP topology correct.” The claim is narrower: the audited classic sparse-indexer group/per-layer width override is absent in the former and present in the latter. Backend support, decode LSE, kernel selection, output correctness, and memory capacity still need their own gates.

Choose a stable version from the matrix

Stable tag	Alignment helper shared with indexer	DCP group width delegated	Operational decision
v0.26.0	No	No	Treat both audited signatures as possible on the affected classic path.
v0.27.0	Yes	No	First stable answer only for the one-column alignment signature.
v0.27.1	Yes	No	Same audited boundary; do not use it as the DCP-factor fix.
v0.28.0	Yes	Yes	First stable candidate containing both fixes; still run the canary.

If the installed image is based on a development build, vendor fork, backport, or cherry-pick, the marketing tag is secondary. Resolve the exact files or commit. A v0.26-labelled image can contain a backport; a v0.28-labelled image can vendor an older source tree. Source wins.

For a clean upstream installation with either audited signature, start the upgrade evaluation at v0.28.0 or a later pinned stable release. That avoids needing two different recommendations. The earlier v0.27.0 boundary remains useful for forensics and tightly constrained fleets that cannot yet change their larger runtime base.

Inspect the installed source without a GPU

Do not import the vLLM runtime merely to print a version on a production host. Python package metadata and installed text files are enough for this source preflight:

from importlib.metadata import distribution
from pathlib import Path

dist = distribution("vllm")
root = Path(dist.locate_file(""))
block_table = (root / "vllm/v1/worker/block_table.py").read_text()
kv_interface = (root / "vllm/v1/kv_cache_interface.py").read_text()

uniform = kv_interface.split("class UniformTypeKVCacheSpecs", 1)[1][:6000]

print("version:", dist.version)
print("shared_alignment_width:", "def get_block_table_width" in block_table)
print(
    "dcp_group_width_override:",
    "def max_num_blocks_per_req" in uniform
    and "self.kv_cache_specs.values()" in uniform,
)

Also hash those files and record the container image digest. The two booleans are evidence for these specific code features, not a general compatibility test. If a vendor renamed classes, split the module, or patched equivalent logic elsewhere, inspect the diff rather than forcing the script to say yes.

For a source checkout, record both the commit and worktree state:

git -C /path/to/vllm rev-parse HEAD
git -C /path/to/vllm status --short

A dirty checkout or unpinned container invalidates a tag-only diagnosis.

Use the ratio as a diagnostic, not a verdict

A tiny offline classifier can prevent the most obvious wrong turn:

def classify_widths(left: int, right: int, dcp_size: int) -> str:
    low, high = sorted((left, right))
    if high - low == 1:
        return "alignment candidate: verify 64-token blocks and PR #50302"
    if dcp_size > 1 and high == low * dcp_size:
        return "DCP candidate: verify group/layer specs and PR #50823"
    return "unmatched: compare widths with old/new max_model_len and audit source"

print(classify_widths(5469, 5470, 1))
print(classify_widths(8192, 16384, 2))
print(classify_widths(2464, 3168, 1))

Expected output:

alignment candidate: verify 64-token blocks and PR #50302
DCP candidate: verify group/layer specs and PR #50823
unmatched: compare widths with old/new max_model_len and audit source

The word candidate matters. Kernel virtual block splitting, non-64 block sizes, DCP rounding, speculative overhang, prefix-cache state, and a different model runner can produce other relationships. The traceback and source path must agree with the arithmetic.

Minimal evidence bundle for an upstream report

Include the exact vLLM version and commit, image digest, model revision, PyTorch/CUDA, GPU and topology, attention backend, resolved KV dtype, block size, TP/DCP/DP/EP, model runner, max_model_len requested and effective, MTP depth, prefix-cache state, complete dimension pair, the first relevant traceback frames, concurrency, input/output lengths, and whether the error reproduces after a clean restart. Remove credentials, prompt content, hostnames, internal IPs, and unrelated environment variables.

Run a one-variable upgrade canary

First reproduce the old failure in a non-production environment with a pinned, sanitized workload. Then change only the vLLM image or source pin. Do not simultaneously change context, cache dtype, model revision, MTP, DCP, driver, and request corpus; a passing run would have no attributable cause.

Gate	What to hold constant	What must pass after the upgrade
Source	Checkpoint, topology, flags, request corpus	Installed files contain the expected matching fix
Width boundary	Old failing odd/even lengths or DCP ratio	No tensor-width exception across repeated runs
Correctness	Frozen prompts and decode settings	Token/output contract meets the baseline tolerance
Service	Concurrency, arrivals, cancellations	No worker death, stuck request, or unexpected restart
Memory	Same context and request mix	Physical free HBM and allocator peaks retain a documented reserve
Performance	Same warmup and measurement window	TTFT, TPOT, accepted throughput, and tails meet the budget
Recovery	Same health checks and orchestration	Intentional restart and rollback restore service predictably

Capture the exact failing pair before the upgrade and confirm its old code path is exercised after it. “We could not make it fail” is weaker than “the same workload crossed the old boundary repeatedly and the service remained correct.”

Test MTP and prefix caching separately

Issue comments broaden the reachability conditions. The primary 350K profile used MTP and disabled prefix caching. A separate H200 profile reproduced 3125 vs 3126 around a 200K limit when long shared prefixes were already in cache and MTP draft tokens extended the active edge. A DGX Spark report linked another exact-multiple overhang path.

Use four explicit arms:

Arm	MTP	Prefix caching	Purpose
Control	Off	Off	Prove plain concurrent decode and the new source pin
Speculation	On	Off	Exercise flattened multi-token decode without cache-hit state
Cache	Off	On	Exercise near-limit shared-prefix hits without draft overhang
Combined	On	On	Recreate the highest-risk interaction after separate arms pass

Sweep both odd and even raw block counts around the old alignment boundary. For DCP, test the intended size and a lower control at the exact production TP and DCP topology. Record accepted outputs, not only server uptime. A service that avoids the exception but silently corrupts or truncates output has not passed.

Handle an old-version workaround carefully

One issue commenter suggested choosing a max_model_len aligned to 128 × dcp_size for an old build. For the simple 64-token, DCP1 alignment calculation, that keeps the raw block count even and avoids the one-column disagreement.

It is an emergency containment, not the fix:

It does not reconcile the DCP group/per-layer formula.
It does not prove MTP cannot extend a request across another block.
It does not cover prefix-cache boundaries or automatic context reduction.
It can move the failure rather than remove the inconsistent calculation.
It leaves the fleet on a known old source path.

Prefer a pinned stable release containing the merged fix. If change control temporarily blocks the upgrade, document the aligned limit, validate all four arms above, preserve the previous limit for rollback, and put an expiry date on the exception.

Do not copy an ad hoc +1 patch from an operator repository into production without reviewing the exact source base. PR #50302 deliberately centralized alignment and virtual block splitting because scattered local padding is how the two sides diverged.

Separate nearby GLM-5.2 failures

The words “runtime,” “FP8,” and “long context” are not enough to group failures.

Symptom	Next guide or source	Why it is different
CUDA OOM inside `sparse_decode_fwd` after a mixed burst	H200 runtime OOM workspace audit	Hidden kernel workspace exceeds physical headroom; no block-table width copy is required
Need to decide whether a pinned H200 backend can enable DCP	Decode context parallelism audit	Backend, LSE, kernel, and correctness eligibility precede this narrow width bug
`2464 vs 3168` after `max_model_len=auto` reduces context	Open PR #46794	InputBatch retains an old-width table; the pair follows two context limits
Immediate OOM while loading weights or capturing graphs	Local hardware guide	Capacity, quantization, loading duplication, or graph pools fail before this decode copy
Output becomes wrong without a tensor exception	Re-run the pinned correctness harness	Absence of the reported exception does not prove kernel or distributed correctness

If the first relevant frame is not in the MLA indexer, stop using this version matrix as a diagnosis. Follow the actual allocation or kernel path.

Rent a test cluster only after preflight

The alignment calculation requires no GPU. Spend on a cluster only when the remaining decision is whether the pinned fixed image survives your real topology and workload. Write down the GPU count and HBM, interconnect, driver, image digest, checkpoint revision, storage and egress, maximum spend, sanitized corpus, pass/fail gates, rollback, and deletion plan before opening capacity.

Run a bounded GLM-5.2 block-table fix canary

Rent only after the logged widths, candidate fix, one-variable image change, concurrency matrix, output checks, spend ceiling, and rollback are frozen. Run the control, MTP, prefix-cache, and combined arms; archive sanitized evidence; then delete only the resources created for the canary.

Check current GPU availability on RunPod →

Affiliate disclosure: This is an affiliate link and a referral link. GLM52.ai may receive a commission or referral credit after qualifying usage at no added charge from us. A rental does not prove that an image contains vLLM PR #50302 or PR #50823, that v0.28.0 resolves a different tensor-width path, or that GPU count, HBM, interconnect, driver, CUDA, vLLM source, checkpoint, storage, egress, price, security, and deletion match this guide. Verify the live SKU, source pins, terms, and acceptance results before use.

If a production-shaped multi-GPU test is not justified, keep the old service isolated, use a documented hosted route, or test a smaller checkpoint for the application layer. Hardware spend cannot repair an unclassified traceback.

Frequently asked questions

Does vLLM v0.27.0 fix the GLM-5.2 `5469 vs 5470` error?

It is the first stable release containing PR #50302’s shared 128-token width calculation, which addresses the audited one-column alignment path. Verify that your image actually contains the helper and that the traceback follows the same sparse indexer. Then rerun the failing workload.

Does vLLM v0.27.1 fix `8192 vs 16384` under DCP2?

Not in the audited tagged source. v0.27.1’s kv_cache_interface.py is byte-identical to v0.27.0 for this class and lacks the group-width override. v0.28.0 is the first stable tag containing PR #50823.

Should I upgrade directly to v0.28.0?

For either audited signature, v0.28.0 is the first stable candidate containing both fixes. Pin its image or commit and run the one-variable canary. Check the current release state again if you are reading later; newer stable releases can supersede this boundary.

Can I fix the error by lowering `max_model_len`?

A lower or specially aligned value can avoid one old alignment boundary, but it does not make the two calculations consistent and does not cover the DCP or auto-reduction paths. Use it only as a time-bounded containment with load tests and an upgrade plan.

Is MTP the root cause?

Not by itself. Issue #46074 reproduced the alignment failure with multiple MTP depths, while the column parity follows max_model_len. MTP and prefix-cache hits can make the edge reachable, so test them as separate workload arms.

Is `fp8_ds_mla` always affected?

No. It identifies the relevant packed cache path in the upstream GLM reports, but version, model runner, backend, block size, topology, and workload determine whether a specific inconsistent width calculation is present and reached.

What if my widths differ by more than one but are not a DCP multiple?

Compare them with the original and effective max_model_len, block size, and kernel block size. Open PR #46794 gives 2464 vs 3168 as an auto-reduction lookalike. If no formula matches, archive the source and report the actual path; do not force it into either fixed issue.

Sources and method

Primary sources checked on August 27, 2026 HKT:

Z.ai GLM-5.2 release and the pinned GLM-5.2-FP8 checkpoint
vLLM issue #46074, PR #50302, and v0.27.0
vLLM issue #50825, PR #50823, and v0.28.0
Open PR #46794 for the auto-reduced-context lookalike

We compared raw tagged source rather than release dates alone. v0.27.0 contains the shared alignment helper and its tag descends from #50302. v0.27.0 and v0.27.1 lack the DCP group override; v0.28.0 contains it and descends from #50823. The deterministic receipt recalculates seven alignment rows and two DCP rows, validates 22 source hashes, and records the zero-runtime boundary.
